G657A2 G657B3 Nylon Fiber Optic FTTH Drop Cable Invisible Transparent

Ask Lasest Price
Brand Name :	SKYLYNN or OEM, ODM
Certification :	ISO, ROHS, CE
Payment Terms :	T/T, L/C, WEST UNION
Supply Ability :	100,000 cores
Delivery Time :	5-10 DAYS

Add to Cart

Product Details
Company Profile

G657A2 G657B3 Nylon Fiber Optic FTTH Drop Cable Invisible Transparent

G657A2 G657B3 Nylon Invisible Transparent Fiber Optic FTTH Drop Cable

Invisible Fiber Optic Patch Cord

1. Solve the indoor environment of homes, offices, commercial
shops, etc. that have been renovated.
2. Without damaging the completed decoration works, without
affecting or having little effect on the decoration effect.
3. No need to wear pipes, no holes, no rivets and other fixing
methods.
4. Along the corner lines, doors and windows, window edges, etc.,
extend the fiber to the home and extend to any corner of the room.
5. Not only is it beautiful, but it can also be installed quickly
and easily with minimal disturbance to the residents, and can
greatly reduce the difficulty of construction and the cost of
materials.

Features
Low insertion loss high return loss

Excellent mechanical endurance

High credibility and stability

Good in repeatability and exchangeability

Application
Fiber optic communication networks

Optical access network

Data processing networks

Premise installations

Optical Characteristics (G657A2)

Characteristics	Conditions	Specified Values	Units
Geometrical characteristics
Cladding diameter	125.0±0.7	µm
Cladding non-circularity	≤0.7	%
Coating diameter	245±5	µm
Coating/cladding concentricity error	≤12	µm
Coating non-circularity	≤6.0	%
Core/cladding concentricity error	≤0.5	µm
Curl	≥4	m
Optical characteristics
1310nm	≤0.35	dB/km
1383nm	≤0.35	dB/km
1550nm	≤0.21	dB/km
Attenuation	1625nm	≤0.23	dB/km
Attenuation vs. Wavelength	1525~1575nm	≤0.02	MHz*km
max. A difference	1525~1575nm	≤0.02	MHz*km
1285~1330nm	≤0.03	MHz*km
Zero dispersion wavelength	1300~1324	nm
Zero dispersion slope	≤0.092	ps/(nm2*km)
Polarization mode dispersion
PMD maximum individual fibre	≤0.1	ps/km1/2
PMD design link value	≤0.06	ps/km1/2
Typical force	0.04	ps/km1/2
Cable cut off wavelength	≤1260	nm
Mode field diameter	1550nm	9.3~10.3	µm
1310nm	8.4~9.3	µm
Group index of refraction	1550nm	1.467
1310nm	1.466
Environmental characteristics	1310nm, 1550nm&1625nm
Temperature cycling	-60℃ to +85℃	≤0.05	dB/km
Temperature-humidity cycling	-10℃ to +85℃,	≤0.05	dB/km
Temperature-humidity cycling	4% to 98% RH	≤0.05	dB/km
Water immersion	23℃, 30 days	≤0.05	dB/km
Dry heat	85℃, 30 days	≤0.05	dB/km
Damp heat	85℃, 85%RH, 30 days	≤0.05	dB/km
Mechanical specification
Proof test	≥9.0	N
≥1.0	%
≥100	kpsi
Macro bending induced loss
1Turns @5mm Radius	1550nm	≤0.15	dB
1Turns @5mm Radius	1625mm	≤0.45	dB
1Turns @7.5mm Radius	1550nm	≤0.08	dB
1Turns @7.5mm Radius	1625mm	≤0.25	dB
1Turns @10mm Radius	1550nm	≤0.03	dB
1Turns @10mm Radius	1625mm	≤0.10	dB
Coating strip force	Typical average force	1.5	N
Peak force	≥1.3 ≤8.9	N
Dynamic stress corrosion susceptibility parameter	27

Specification

SPECIFICATION	UNIT	4F	6F	8F	12F	24F
Nominal Cable Diameter	mm	5.8	6.2	6.8	6.6	8.2
Nominal Weight	kg/km	28	33	36	41	58
Temperature Range	°C	-10 to 70
Max Pulling Tension	N	600	600	600	600	900
Max. Crush Resistance	N/100 mm	500	500	500	500	500
Long Term Crush	N/100 mm	250	250	250	250	250
Min. Bending Radius – Under Load	mm	120	124	136	144	160
Min. Bending Radius – No Load	mm	89	93	102	108	120
Colour Code for fibres & tubes	Blue, Orange, Green, Brown, Grey, White, Red, Black, Yellow, Violet, Pink, Aqua
