MPO ODVA Type Outdoor Patch Cord RRH 5mm 7mm Multi Purpose FTTX

ODVA Type FTTA Outdoor Patch Cord

Description

This outdoor waterproof connector attaches to adapter on panel of RRH. The common LC connector pair inside allows easier testing and cleaning. There are two types of connector plugs available: threaded and easy-connect bayonet.Harsh environments where chemicals,corrosive gases and liquids are commonplace.Telecommunication/CATV Systems.FTTX and Special environmental.Mobile routers and internet hardware.

Application

Multi-purpose Outdoor.
For connection between distribution box and RRH.
Deployment in Remote Radio Head cell tower applications.

Features

Cost effective solution for in house termination
IP67 water and dust protection
Wide range of operational temperature for outside plant -40 to +85°C
Different cable diameter can be available
Intermatable to other Industrial LC adaptor per IEC 61076-3-106
No need special tools for assembly

GYFJH Cable Specifications

Cable Type 1:

Fiber Count	Cable Dimension mm	Cable Weight kg/km	Tensile N		Crush N/100mm		Min. Bend Radius mm		Range of Temperature
			Long Term	Short Term	Long Term	Short Term	Dynamic	Static
1--12	5	25	350	700	1000	2000	20D	10D	--30-70℃
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2. The cable dimension and weight are subject to the simplex cable of 2.0 outer diameter; 3. D is outer diameter of the round cable;

MPO ODVA Type Outdoor Patch Cord RRH 5mm 7mm Multi Purpose FTTX

Cable Type 2:

Fiber Count	Cable Dimension mm	Cable Weight kg/km	Tensile N		Crush N/100mm		Min. Bend Radius mm		Range of Temperature
			Long Term	Short Term	Long Term	Short Term	Dynamic	Static
1--12	7	45	400	800	1000	2000	20D	10D	--3-70℃,
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2. The cable dimension and weight are subject to the simplex cable of 2.0 outer diameter; 3. D is outer diameter of the round cable;

MPO ODVA Type Outdoor Patch Cord RRH 5mm 7mm Multi Purpose FTTX

ODVA Patchcords Specifications

Item	Data
Insertion Loss	≤0.3dB
Return Loss	SM/UPC≥55dB, SM/APC≥60dB, MM≥35dB
Mechanical life	500cycles
Working temperature	-20°C~+70°C
Storage temperature	-20°C~+70°C
Tensile Data	Tensile between junction and fiber cable≥100N
