Optical Fibre GYFTA Underground G652 Single Mode Fiber Optic Cable 1550nm Unarmored

Ask Lasest Price
Brand Name :	SKYLYNN or OEM, ODM
Certification :	ISO, ROHS, CE
Delivery Time :	5-10 DAYS
Payment Terms :	T/T, L/C, WEST UNION
Supply Ability :	100,000 cores

Add to Cart

Product Details
Company Profile

Optical Fibre GYFTA Underground G652 Single Mode Fiber Optic Cable 1550nm Unarmored

Outdoor Stranded Loose Tube Duct Un-armored Fiber Optic Cable GYFTA

Description

The unarmored cable has high water resistance ,high crush resistance, good flexibility and bending performance. You can choose fibre Type, sheath material and colour code of unarmored cable. The unarmored cable is mainly applicated in aerial and duct.

Features

Choice of Fibre Type
Colour code of Fibre
High water resistance
High crush resistance
Choice Sheath Material
Low attenuation and dispersion
Good flexibility and bending performance

Appicable

Aerial, Duct

Optical Characteristics

		G.652	G.655	50/125μm	62.5/125μm
Attenuation	@850nm			≤3.0 dB/km	≤3.0 dB/km
(+20℃)	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength λcc		≤1260nm	≤1480nm

Technical Parameters

Cable Type	Fiber Count	Tubes	Fillers	Cable Diameter mm	Cable Weight kg/km	Tensile Strength Long/Short Term N	Crush Resistance Long/Short Term N/100mm	Bending Radius Static /Dynamic mm
GYFTA-2~6	2~6	1	4	9.7	90	600/1500	300/1000	10D/20D
GYFTA-8~12	8~12	2	3	9.7	90	600/1500	300/1000	10D/20D
GYFTA-14~18	14~18	3	2	9.7	90	600/1500	300/1000	10D/20D
GYFTA-20~24	20~24	4	1	9.7	90	600/1500	300/1000	10D/20D
GYFTA-26~30	26~30	5	0	9.7	90	600/1500	300/1000	10D/20D
GYFTA-32~36	32~36	6	0	10.2	104	1000/3000	300/1000	10D/20D
GYFTA-38~48	38~48	4	1	11	117	1000/3000	300/1000	10D/20D
GYFTA-50~60	50~60	5	0	11	117	1000/3000	300/1000	10D/20D
GYFTA-62~72	62~72	6	0	11.5	126	1000/3000	300/1000	10D/20D
GYFTA-74~84	74~84	7	1	13.4	154	1000/3000	300/1000	10D/20D
GYFTA-86~96	86~96	8	0	13.4	154	1000/3000	300/1000	10D/20D
GYFTA-98~108	98~108	9	1	14.8	185	1000/3000	300/1000	10D/20D
GYFTA-110~120	110~120	10	0	14.8	185	1000/3000	300/1000	10D/20D
GYFTA-122~132	122~132	11	1	16.9	228	1000/3000	300/1000	10D/20D
GYFTA-134~144	134~144	12	0	16.9	228	1000/3000	300/1000	10D/20D
